D-CONNECT Category 6 S/FTP Cable is a premium-performance shielded Ethernet cable engineered to deliver robust and interference-free data transmission in high-speed networking environments. Constructed with 23 AWG solid bare copper conductors, individually foil-shielded pairs, and an overall braided shield, it ensures superior immunity to electromagnetic interference (EMI) and crosstalk. The low smoke zero halogen (LSZH) jacket enhances fire safety by minimizing toxic gas emissions, making it ideal for use in public buildings, data centers, and enclosed spaces where fire performance is critical.
ANSI/TIA-568.2-D: Balanced twisted-pair telecommunications cabling and components
ISO/IEC 11801-1: Generic cabling for customer premises
IEC 61156-5: Multicore and symmetrical pair/quad cables for digital communications
EN 50173-1: Information technology – cabling systems for buildings
IEC 60512-99-001: Test specifications for connectors
🔌 Application Standards
IEEE 802.3: Compliant with 10BASE-T, 100BASE-TX, and 1000BASE-T (Gigabit Ethernet)
PoE & PoE+: Supports IEEE 802.3af (PoE) and IEEE 802.3at (PoE+)
100VG-AnyLAN, ATM, Digital/Analog Video
🔥 Fire Safety & Environmental Standards
IEC 60332-1 / IEC 60332-3-22: Flame propagation tests
IEC 61034-2: Smoke density test
IEC 60754-1 / IEC 60754-2: Acid gas emission tests
RoHS Compliant: Restriction of hazardous substances
| Component | Specification |
| Cable Type | Category 6 S/FTP (Shielded Foiled Twisted Pair) |
| Conductor | 23 AWG Solid Bare Copper |
| Insulation | Foamed Polyolefin / HDPE |
| Shielding | Individual foil shielding on each pair + overall braided shield |
| Separator | Central Cross Filler (Non-metallic) |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Outer Jacket Color | Grey (RAL 7035 or custom options available) |
| Outer Diameter | Approx. 7.2 ± 0.3 mm |
| Rip Cord | Yes |
| Packaging | 305m Pull Box or Wooden Drum (custom options available) |
| Category | Parameter | Specification |
| Electrical | Mutual Capacitance | ≤ 5.6 nF / 100 m |
|  | Capacitance Unbalance | ≤ 330 pF / 100 m |
|  | Insulation Resistance | ≥ 500 MΩ |
| Â | Voltage Rating | Max. 72 VDC |
| Â | Dielectric Strength | 2.5 kV DC for 2 seconds |
| Â | Nominal Velocity of Propagation (NVP) | 69% |
|  | Impedance (1–250 MHz) | 100 ± 15 Ω |
|  | Delay Skew (1–250 MHz) | ≤ 45 ns / 100 m |
|  | DC Resistance @ 20 °C | ≤ 9.38 Ω / 100 m |
|  | DC Resistance Unbalance | ≤ 5.0% |
| Mechanical | Minimum Bending Radius | < 4 × Cable Diameter |
| Â | Maximum Pulling Force | 11.5 kg |
|  | Cable Weight (305 m) | Approx. 12–13 kg |
| Environmental | Operating Temperature | –20 °C to +70 °C |
|  | Storage Temperature | 0 °C to +60 °C |
|  | Installation Temperature | 0 °C to +50 °C |
| Flame | Flame Test | IEC 60332-1 / IEC 60332-3-22 |
| Â | Smoke Density Test | IEC 61034-2 |
| Â | Acid Gas Emission | IEC 60754-1 / IEC 60754-2 |
|  | Cold Bend Test (–20 °C ±2 °C × 4h) | No visible cracks @ 8× cable O.D. |
| Â | Jacket Type | LSZH, Halogen-Free, Flame Retardant |
| CC-C6-S/FTP-LZ-305-VL | CAT6 S/FTP Cable – 23 AWG, Shielded Foiled Twisted Pair, LSZH Jacket, Grey |
