The DConnect 1U High Density Fiber Patch Panel is a compact 19-inch rack-mounted fiber management solution designed to support up to 96 fibers and 4 × 24F MPO cassette modules. Ideal for data centers, telecom networks, enterprise infrastructure, and high-speed optical deployments.
Server Infrastructure
Network Deployment
Business Systems
Surveillance Networks
The DConnect 1U High Density Fiber Patch Panel is engineered to provide efficient fiber distribution, structured cable management, and scalable connectivity for modern optical networking environments. Designed in a compact 1U 19-inch rack-mounted format, the panel supports up to 96 fiber connections through MPO cassette modules or adapter plates, maximizing rack space utilization without compromising performance. Its modular architecture allows flexible deployment for MPO pre-terminated systems, fiber splicing applications, and adapter-based installations. Built with a durable SPCC steel body and optimized internal routing system, the panel helps maintain proper bend radius protection while ensuring organized cable management. Suitable for data centers, telecom facilities, enterprise networks, and ISP infrastructures, the DConnect 1U High Density Fiber Patch Panel delivers a reliable and future-ready fiber connectivity solution.
The DConnect 1U High Density Fiber Patch Panel features a compact rack-mounted design that supports up to 96 fibers within a single rack unit, making it ideal for high-density fiber deployments. It accommodates up to 4 × 24F MPO cassette modules and supports adapter plates for LC, SC, ST, FC, and MPO connectivity requirements. The pluggable MPO cassette system simplifies installation, upgrades, and maintenance while reducing downtime in critical network environments. Its modular construction provides flexibility for network expansion, fiber splicing, and pre-terminated backbone deployments. Manufactured with a robust SPCC steel enclosure and high-quality powder-coated finish, the panel ensures durability and long-term performance. Optimized internal fiber routing enhances cable organization, protects bend radius requirements, and supports reliable optical transmission across enterprise, telecom, and data center infrastructures.
The DConnect DC-FM4M1 1U High Density Fiber Patch Panel is designed to meet the increasing demands of modern fiber optic networks where scalability, performance, and space efficiency are essential. Supporting up to 96 fibers within a compact 1U rack-mounted enclosure, the panel offers an ideal solution for high-density fiber management in data centers, telecommunications facilities, internet service provider networks, and enterprise environments. The modular front design allows integration of MPO cassette modules or adapter plates, enabling flexible network architectures and simplified future expansion. Its pluggable cassette structure reduces installation time and allows technicians to perform maintenance or upgrades with minimal disruption to network operations. The enclosure is constructed from premium SPCC steel with a durable black powder-coated finish, providing excellent protection and long-term reliability. Advanced cable management features ensure organized fiber routing and bend radius control, helping maintain signal integrity and network performance. Whether deployed for MPO backbone systems, fiber distribution, cross-connect applications, or optical network expansion, the DConnect 1U High Density Fiber Patch Panel delivers professional-grade fiber management for next-generation communication infrastructures.
| Product Name | 1U High Density Fiber Patch Panel |
|---|---|
| Brand | DConnect |
| Model | DC-FM4M1 |
| Part Number | DC-FM4M1-XX |
| Mounting Type | 19-Inch Rack Mount |
| Form Factor | 1U |
| Width | 482.6 mm |
| Mounting Width | 465.1 mm |
| Depth | 436.2 mm |
| Height | 43.8 mm |
| MPO Cassette Capacity | Up to 4 × 24F MPO Cassettes |
| Maximum Fiber Capacity | 96 Fibers |
| Front Configuration | MPO Cassette or Adapter Plate |
| Cassette Type | Pluggable MPO Cassette |
| Adapter Compatibility | LC |
| Adapter Compatibility 2 | SC |
| Adapter Compatibility 3 | ST |
| Adapter Compatibility 4 | FC |
| Adapter Compatibility 5 | MPO |
| Material | SPCC Steel Body |
| Top Cover Material | Aluminum |
| Surface Finish | Black Powder Coating |
| Fiber Management | Bend Radius Protection |
| Cable Entry | Rear Cable Entry Ports |
| Mounting Accessories | Rack Brackets Included |
| Compliance | ISO, ANSI/TIA, IEC, CE, RoHS |
Contact us for details and support.
