The DCONNECT Multimode Fiber Patch Cord is a premium LSZH fiber optic patch cable designed for high-speed optical networking. Available in OM2, OM3, OM4, and OM5 fiber grades with simplex and duplex configurations, it delivers low insertion loss, excellent signal integrity, and reliable connectivity for data centers, enterprise networks, telecom, and FTTH applications.
Server Infrastructure
Network Deployment
Business Systems
Surveillance Networks
The DCONNECT Multimode Fiber Patch Cord is a high-performance fiber optic connectivity solution engineered for short-distance, high-bandwidth optical communication networks. Available in OM2, OM3, OM4, and OM5 multimode fiber grades, this patch cord delivers exceptional optical performance for data centers, enterprise LANs, storage networks, telecommunications, and FTTH infrastructures. Manufactured using precision ceramic ferrules and premium multimode optical fiber, it provides ultra-low insertion loss, high return loss, and stable signal transmission. Available in simplex and duplex configurations with multiple connector combinations including LC, SC, ST, FC, E2000, and MTRJ, the DCONNECT Multimode Fiber Patch Cord offers maximum installation flexibility. The LSZH jacket improves safety in enclosed environments while maintaining excellent durability, making it the ideal solution for modern high-speed fiber optic networks requiring dependable performance and long service life.
The DCONNECT Multimode Fiber Patch Cord is designed to deliver outstanding optical performance for high-speed fiber optic communication systems. Supporting OM2, OM3, OM4, and OM5 multimode fibers, it provides flexible deployment across enterprise networks, data centers, storage systems, and telecom infrastructures. The precision zirconia ceramic ferrule minimizes insertion loss while maintaining excellent return loss for stable signal transmission. Available in simplex and duplex configurations with multiple connector options including LC, SC, ST, FC, MTRJ, and E2000, the patch cord integrates easily into virtually any fiber network. The premium LSZH jacket provides superior fire safety, flexibility, and mechanical protection, while dust caps protect connector end faces during transportation and installation. Every patch cord is factory tested to guarantee consistent optical performance, reliability, and compliance with international fiber optic standards.
The DCONNECT Multimode Fiber Patch Cord is manufactured to provide superior optical connectivity for modern high-speed communication networks. Designed for short-distance applications requiring high bandwidth and low signal attenuation, the patch cord is available in OM2, OM3, OM4, and OM5 multimode fiber variants to support different transmission speeds and distances. Its precision-polished ceramic ferrules ensure accurate fiber alignment, minimizing insertion loss and maximizing signal stability throughout the network. Compatible with LC, SC, ST, FC, E2000, APC, and MTRJ connector interfaces, the patch cord supports a wide range of networking equipment including switches, servers, patch panels, storage systems, and optical distribution frames. The durable LSZH outer jacket provides excellent flexibility while reducing smoke and toxic emissions during fire conditions, making it suitable for commercial buildings, hospitals, airports, and data centers. Every cable undergoes comprehensive factory testing for insertion loss, return loss, and environmental durability, ensuring dependable long-term performance in mission-critical fiber optic infrastructures.
| Product Type | Multimode Fiber Patch Cord |
|---|---|
| Part Number | PC-XXX-XXX-XXX-X-X-XX |
| Fiber Type | OM2, OM3, OM4, OM5 |
| Core Size | 50/125 μm |
| Cable Configuration | Simplex / Duplex |
| Connector Options | LC, SC, ST, FC, MTRJ, E2000, APC |
| Connector Polish | UPC / APC |
| Ferrule Material | Zirconia Ceramic |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Cable Diameter | 2.0 ± 0.2 mm |
| Cable Color | Black (Custom Colors Available) |
| Insertion Loss | ≤ 0.25 dB |
| Return Loss | ≥ 30 dB |
| Operating Wavelength | 850 nm / 1300 nm |
| Attenuation @ 850 nm | ≤ 3.5 dB/km |
| Attenuation @ 1300 nm | ≤ 1.5 dB/km |
| Bandwidth OM2 | 500 MHz·km @ 850 nm |
| Bandwidth OM3 | 2000 MHz·km @ 850 nm |
| Bandwidth OM4 | 4700 MHz·km @ 850 nm |
| Bandwidth OM5 | 4700 MHz·km @ 850 nm |
| Minimum Bend Radius | 10× OD (Static), 20× OD (Dynamic) |
| Tensile Strength | 100 N Short Term / 50 N Long Term |
| Durability | ≥ 500 Mating Cycles |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Compliance | IEC 61754, IEC 61300, IEC 60793-2-10, ISO/IEC 11801, TIA/EIA-568-C.3, RoHS, REACH, CE |
Contact us for details and support.
