The DConnect Wall Mount Network Cabinet is a durable 19-inch rack enclosure designed for networking, telecom, CCTV, and IT equipment installations. Manufactured from high-quality SPCC steel with secure cable management, excellent ventilation, and wall-mounted flexibility for professional network deployments.
Server Infrastructure
Network Deployment
Business Systems
Surveillance Networks
The DConnect Wall Mount Network Cabinet is a professional 19-inch rack enclosure engineered to provide secure, organized, and space-efficient installation of networking and telecommunications equipment. Designed for offices, data rooms, CCTV systems, educational institutions, retail environments, and enterprise networks, the cabinet combines heavy-duty steel construction with excellent accessibility, cable management, and equipment protection. Its welded frame, removable side panels, and wide-opening front door simplify installation and maintenance, while optional cooling fan support helps maintain optimal operating temperatures. Built to international rack standards, the cabinet offers a reliable and scalable solution for structured cabling and network infrastructure.
The DConnect Wall Mount Network Cabinet is manufactured using premium SPCC cold-rolled steel with a fully welded frame to provide excellent structural strength and long-term durability. Designed to support standard 19-inch rack equipment, it offers compatibility with switches, patch panels, routers, DVRs, NVRs, and telecom devices. The cabinet features a front door with over 180-degree opening for convenient equipment access, removable side panels for simplified maintenance, and integrated cable entry knockouts for clean cable management. Optional 120mm cooling fan support improves airflow and equipment reliability, while the corrosion-resistant powder-coated finish protects the cabinet in demanding environments. Supporting wall-mounted or floor-standing installation with optional castors and adjustable feet, the cabinet delivers flexible deployment for modern IT and networking infrastructures.
The DConnect Wall Mount Network Cabinet is designed to provide professional-grade protection and organization for network infrastructure in environments where floor space is limited. Manufactured from high-strength SPCC cold-rolled steel, the cabinet features a rigid welded construction capable of supporting static loads up to 60 kg while ensuring long-term structural integrity. Designed around the internationally recognized 19-inch rack standard, it accommodates networking equipment including switches, patch panels, routers, fiber optic equipment, DVRs, NVRs, and communication devices. The cabinet incorporates removable side panels and a front door that opens beyond 180 degrees, allowing technicians quick access for installation, upgrades, and maintenance. Multiple cable entry knockouts enable organized cable routing from both the top and bottom of the enclosure, while optional 120mm cooling fans improve airflow for heat-sensitive equipment. Finished with a durable powder-coated surface following degreasing and phosphating treatments, the cabinet offers superior corrosion resistance and long service life. Complying with major international rack enclosure standards, the DConnect Wall Mount Network Cabinet is an ideal solution for enterprise networks, structured cabling systems, telecom installations, CCTV infrastructure, and small server rooms.
| Product Name | Wall Mount Network Cabinet |
|---|---|
| Brand | DConnect |
| Part Number | DC-SC-6406 |
| Cabinet Type | Single Section Wall Mount Cabinet |
| Rack Standard | 19 Inch Rack |
| Rack Height | 6U |
| Cabinet Width | 600 mm |
| Cabinet Depth | 450 mm |
| Mounting Type | Wall Mount / Floor Standing |
| Material | SPCC Cold-Rolled Steel |
| Mounting Profile Thickness | 1.5 mm |
| Panel Thickness | 1.2 mm |
| Frame Construction | Fully Welded |
| Maximum Static Load | 60 kg |
| Front Door Opening | Over 180° |
| Side Panels | Removable |
| Cable Entry | Top & Bottom Knockouts |
| Cooling Support | 120 mm Fan (Optional) |
| Surface Finish | Powder Coated |
| Corrosion Protection | Degreased & Phosphated |
| Color | Black (RAL Available) |
| Compliance | ANSI/EIA RS-310-D |
| Standards | DIN41494, DIN41497, GB/T3047.2-92 |
Contact us for details and support.
